On/Off-gridSolar Inverters are also commonly referred to as:
Energy Storage and Grid-Tied Inverter, Battery Energy Storage System (BESS) with Grid-Tied Inverter, Energy Storage Hybrid Inverter, Off-Grid Battery Inverter with Grid Connection, Storage-Integrated Grid-Tied Inverter.
Click here to submit your RFQ, an even more favorable QUOTE will be offered within 1 day
InquiryApplications:
TheEnergy Storage and Grid-Tied Inverter inverters are used in solar energy systems, microgrid setups, off-grid applications, and energy management systems to store excess energy or feed it back into the grid for increased efficiency and reliability.
Parameters:
Output Power:
●Rated Power: 5000W
●Max. Peak Power: 10000VA
Output Voltage Range:
●AC: 230Vac (Single-phase)
Parallel Capacity:
●1-6 units（single/three phase）
Input Voltage Range:
●AC: 90-280V
●DC: 40-60V
Battery Type Supported:
●Lithium-ion/Lead-acid / User-define
Efficiency:
●99.9%
Protection Level (IP Rating):
●IP20/IP65
Communication Interface:
●RS485 / USB/ Dry contact / Wi-Fi/GPRS
Description:
Features:
Hybrid Functionality:Seamlessly switch between on-grid and off-grid modes, ensuring uninterrupted power supply even during grid outages.
Intelligent Power Management:Optimize energy consumption and maximize self-sufficiency with advanced MPPT tracking and battery management system.
Flexible Battery Compatibility:Supports a wide range of lithium-ion and lead-acid batteries for customized energy storage solutions.
Safe and Reliable:Equipped with comprehensive safety features and industry-leading certifications for peace of mind.
Easy Installation and Monitoring:Simplified setup process and intuitive monitoring interface for convenient user experience.
Advantages:
Energy Independence:Reduce reliance on the grid and achieve energy self-sufficiency by storing excess solar power for later use.
Lower Electricity Bills:Slash your energy costs by utilizing solar power and stored energy during peak demand periods.
Environmental Sustainability:Contribute to a cleaner future by reducing carbon emissions and promoting renewable energy use.
Uninterrupted Power Supply:Enjoy peace of mind with a reliable backup power source during grid outages or emergencies.
Versatile Applications:Ideal for residential, commercial, and off-grid installations, providing flexible energy solutions for diverse needs.
Benefits:
Empower Your Energy Independence:Take control of your energy consumption and become less reliant on the traditional grid.
Maximize Your Solar Investment:Store excess solar energy and use it when you need it most, maximizing the benefits of your solar panels.
Protect Your Home and Business:Ensure uninterrupted power supply during grid outages or emergencies, safeguarding your appliances and devices.
Reduce Your Carbon Footprint:Make a conscious choice towards a sustainable future by harnessing clean and renewable solar energy.
Enjoy Hassle-Free Operation:Easy installation, intuitive monitoring, and comprehensive safety features
Specifications:
| Model | ASI-YP-5K-S |
| Inverter Output | |
| Rated Output Power | 5,000W |
| Max.Peak Power | 10,000VA |
| Rated Output Voltage | 230Vac（L/N/PE single-phase） |
| Load Capacity of Motors | 4HP |
| Rated AC Frequency | 50/60Hz |
| Waveform | Pure sine wave |
| Switch Time | 10ms（typical） |
| Parallel Capacity | 1-6 units（single/three phase） |
| Battery | |
| Battery Type | Lithium-ion / Lead-acid / User-define |
| Rated Battery Voltage | 48Vdc |
| Voltage Range | 40～60Vdc |
| Max.MPPT Charging Current | 100A |
| Max.Mains/Generator Charging Current | 60A |
| Max.Hybrid Charging Current | 100A |
| PV Input | |
| Num. of MPPT | 1 |
| Max.PV array power | 5,500W |
| Max.input current | 22A |
| Max.Voltage of Open Circuit | 500Vdc |
| MPPT Voltage Range | 120～450Vdc |
| Mains / Generator Input | |
| Input Voltage Range | 90～280Vac |
| Frequency Range | 50/60Hz |
| Bypass Overload Current | 40A |
| Efficiency | |
| MPPT Tracking Efficiency | 99.9% |
| Max. Battery Inverter Efficiency | 92% |
| General | |
| Dimensions | 446.9×350×133mm |
| Weight | 13kg |
| Protection Degree | IP20，indoor only |
| Operating Temperature Range | -10~55℃ |
| Noise | ≤60dB |
| Cooling Method | Forced air cooling with adjustable air speed |
| Warranty | 2 years |
| Communication | |
| Embedded Interfaces | RS485 / USB / Dry contact |
| External Modules （Optional） | Wi-Fi/GPRS |
| Certification | |
| Safety | CE（IEC62109-1/2） |
| EMC | EN61000 |
| RoHS | Yes |
