10kwh 15kwh 20kwh stacked lithium battery all in one energy storage LiFePo4 battery with 5kw inverter
Short Description
The stacked lithium energy storage battery use long working life LiFePO4 cell, high performance BMS to protect and manage the battery system. The max series is 5 pcs, free combination for the capacity and meet all kinds of demand for home/industry
- Description
Description：
| Model | ALB-ESS-5K-5KWH | ALB-ESS-5K-10KWH | ALB-ESS-5K-15KWH | ALB-ESS-5K-20KWH | ALB-ESS-5K-25KWH |
| stacked lithium battery | |||||
| Single module capacity | 5.12kwh | ||||
| Module number | 1pcs | 2pcs | 3pcs | 4pcs | 5pcs |
| Total capacity | 5.12kwh | 10.24kwh | 15.36kwh | 20.48kwh | 25.6kwh |
| Standard voltage | 51.2V | ||||
| Working voltage | 43.2V-57.6V | ||||
| Standard discharge current | 100A | 200A | 300A | 400A | 500A |
| Standard charging current | 50A | 100A | 150A | 200A | 250A |
| Suggested DOD | 80% | ||||
| Humidity | 20%-60% | ||||
| Installation | Stacked | ||||
| IP rating | IP20 | ||||
| Communication | CAN/RS485/RS232(WIFI,bluetooth is optional and need extra cost) | ||||
| Product size / unit | 550*500*185mm | ||||
| N.W. / unit | 40kgs | ||||
| Battery Input | |||||
| Battery type | LFP | ||||
| Rated Battery Input Voltage | 48V(Minimum Start up Voltage 44V) | ||||
| Hybrid Charging Maximum Charging Current | 80A | ||||
| Battery Voltage Range | 40VDC~60VDC±0.6VDC (Under voltage Warning / Shutdown Voltage / Overvoltage Warning / Overvoltage Recovery...) | ||||
| Solar Input | |||||
| Maximum PV Open-circuit Voltage | 500VDC | ||||
| PV Working Voltage Range | 120-500VDC | ||||
| MPPT Voltage Range | 120-450VDC | ||||
| Maximum PV Input Current | 18A | ||||
| Maximum PV Input Power | 5200W | ||||
| Maximum PV Charging Current | 80A | ||||
| AC Input（generator/grid） | |||||
| Mains Maximum Charging Current | 60A | ||||
| Rated Input Voltage | 220/230VAC | ||||
| Input Voltage Range | UPS Mains Mode：(170VAC~280VAC)±2%, APL Generator Mode：(90VAC-280VAC)±2% | ||||
| Frequency | 50Hz/60Hz (Automatic Detection) | ||||
| Mains Charging Efficiency | >95% | ||||
| Switch Time (by pass and inverter) | 10ms(Typical Value) | ||||
| Maximum By pass Overload Current | 40A | ||||
| AC Output | |||||
| Output Voltage Waveform | Pure Sine Wave | ||||
| Rated Output Voltage (VAC) | 230VAC(200/208/220/240VAC） | ||||
| Rated Output Power(VA) | 5000（4350/4500/4800/5000） | ||||
| Rated Output Power(W) | 5000（4350/4500/4800/5000） | ||||
| Peak Power | 10000VA | ||||
| On-load Motor Capacity | 4HP | ||||
| Output Frequency Range(Hz) | 50Hz±0.3Hz/60Hz±0.3Hz | ||||
| Maximum Efficiency | >90% | ||||
| No-load Loss | Non Energy-saving Mode: ≤50W, Energy-saving Mode：≤25W(Manual Set up） | ||||
